产品平台化-应用快速开发
组件模块化-功能易于扩展
Infineon TRAVEO™ T2G CYT2B6 Cortex® -M4 Single @80Mhz+CM0+, ASIL B
Quectel AG571 Arm® Cortex®-A7 @1.5Ghz, 2850 DMIPS，车规级
5G SA & NSA、全网通6模16频
5G NR: 2.4Gps(DL)/550Mbps(UL)
LTE: 1.6Gps(DL)/200Mbps(UL)
GPS/GLONASS/BeiDou/Galileo/QZSS
2.5m CEP
16GB
2 x CAN/CAN FD
1 x GNSS Antenna
1 x 2.4G Wi-Fi Antenna
1 x 5G Wi-Fi Antenna
4 x MIMO Antenna
1 x SOS Push in
1 x Crash in
1 x ACC in
1 x 1000BASE-T1
1 x SOS LED out
1 x Microphone in
1 x Amplifier out
DC 6.5V ~ 18V
-40℃ ~ +85 ℃
IP50
224mm x 125.5mm x 32mm
技术文档
